Showcase Product Detail

Audio Accounts Products Images
New Units » Yamaha » Wolverine 450 Auto. 4X4
Model Quick Search

$9,099.00

2009 Yamaha Wolverine 450 Auto. 4X4
Request a Quote Financing Calculator Request a Brochure Financing Form
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

    Key Features
    • The Wolverine 450 4x4 combines features like 4WD and a fully automatic transmission with light weight, sport-tuned adjustable suspension. The result is a highly functional machine that’s a blast to ride.
    • A liquid-cooled 421cc single feeds power through a full-auto constantly variable transmission. The Wolverine 450 is a great explorer.
    • A fully automatic transmission and Yamaha On-Command® gear selector system means switching from 2WD to 4WD is as simple as jabbing the handlebar-mounted button.
    • Raptor™-inspired styling includes aggressive bodywork with integrated floorboards, a comfortable sport seat and an integrated rear rack.
    • Raptor-inspired styling includes aggressive bodywork with integrated floorboards, a comfortable sport seat and an integrated rear rack.
    • Sport-tuned suspension, radial sport tires and light weight add up to an excellent-handling ATV.
    • Pushbutton electric starting for quick easy starts in nearly any condition.
    Engine Features
    • Powerful 421cc liquid-cooled, SOHC four-stroke single is torquey, revvable, smooth-running and extremely reliable.
    • A semi-oval slide 33mm BSR Mikuni® carburetor and high-output DC-CDI ignition deliver great throttle response and performance at all rpm.
    • Fully automatic transmission is extremely rugged and reliable with a constant belt-tensioning system, which provides confident downhill engine braking.
    • A large-capacity aluminum radiator provides maximum cooling efficiency and is positioned high in frame for optimal protection.
    • Easy-access, tool-free air filter simplifies that task.
    • An automatic cam chain tensioner reduces maintenance requirements.
    Chassis/Suspension Features
    • Light, high-tensile steel frame provides a strong foundation for double-wishbone front and single-shock rear long-travel suspension systems for a sporty yet comfortable ride.
    • Five-way preload-adjustable suspension front and rear lets the Wolverine 450 be dialed in just right for varying loads and conditions.
    • A dry weight under 516 pounds means the Wolverine 450 runs right with the big sport dogs.
    • Low-maintenance shaft drives provide near-bulletproof strength and reliability.
    • Front and rear hydraulic disc brakes provide plenty of stopping power.
    • 23x8-12 radial sport tires up great traction and quick, light handling.
    • Aluminum wheels mean low unsprung weight for great suspension action and overall performance.
    • Full skid plates provide great undercarriage protection.
    Additional Features
    • A digital dash meter keeps track of speed and other essentials.
    • An underseat storage compartment and integrated rear cargo rack make it easy to bring the things you need.
    Engine Specifications
    • Type: 421cc liquid-cooled 4-stroke; SOHC, 2 valves
    • Bore x Stroke: 84.5mm x 75.0mm
    • Compression Ratio: 10:1
    • Carburetion: Mikuni® 33mm BSR
    • Ignition: DC – CDI
    • Starting System: Electric
    • Transmission: Yamaha Ultramatic® V-Belt / F,N,R
    • Drive Train: Yamaha On-Command® pushbutton 2WD, 4WD ; Shaft
    Chassis Specifications
    • Suspension/Front: Independent double wishbone; 5-way preload-adjustable shocks, 6.3-in travel
    • Suspension/Rear: Swingarm; 5-way preload-adjustable, 7.1-in travel
    • Brakes/Front: Dual hydraulic disc
    • Brakes/Rear: Hydraulic Disc
    • Tires/Front: AT23 x 8-12 Radial
    • Tires/Rear: AT23 x 10-12 Radial
    Dimensions
    • L x W x H: 77.9 x 41.9 x 43.1 in
    • Seat Height: 33.1 in
    • Wheelbase: 48.5 in
    • Turning Radius: 118”
    • Ground Clearance: 8.7 in
    • Fuel Capacity: 3.8 gal
    • Dry Weight: 516 lb
    • Towing Capacity: 1102 lb with optional hitch
    Other
    • Instrumentation: Digital speedometer, odometer
    • Lighting: Dual 30W Krypton multi-reflector headlights & 21/5W brakelight
    • Warranty: 6 Month (Limited Factory Warranty)
    • Color: Team Yamaha Blue/White

    Specifications

    Engine
    Engine Type 4-stroke; SOHC, 2 valves
    Displacement 421 cc
    Bore x Stroke 84.5 x 75.0 mm
    Engine Cooling Liquid-cooled
    Fuel System Mikuni® 33 mm BSR
    Starting System Electric
    Chassis
    Front Suspension Independent double wishbone; 5-way preload-adjustable shocks
    Front Travel 6.3 in.
    Front Brake Type Dual hydraulic disc
    Front Tires AT23 x 8-12 Radial
    Rear Suspension Swingarm; 5-way preload-adjustable
    Rear Travel 7.1 in.
    Rear Brake Type Hydraulic Disc
    Rear Tires AT23 x 10-12 Radial
    Frame High-tensile steel
    Dimensions/Capacities
    Dry Weight 516 lbs
    Towing Capacity 1102 lbs with optional hitch
    Fuel Capacity 3.8 gal
    Ground Clearance 8.7 in.
    Machine Dimensions (LxWxH) 77.9 x 41.9 x 43.1 in.
    Wheelbase 48.5 in.
    Drive Train
    Drive Train Yamaha On-Command® pushbutton 2WD, 4WD ; Shaft
    Transmission Yamaha Ultramatic® V-Belt / F,N,R
    General
    Speedometer Digital
    Odometer Digital
    Lighting Dual 30W Krypton multi-reflector headlights & 21/5W brakelight
    Colors Team Yamaha Blue/White
    Warranty 6 Month (Limited Factory Warranty)

    Compare Models

    		 Print








    Year 2009
    Manufacturer Yamaha
    Model Wolverine 450 Auto. 4X4
    Style Sport
    MSRP* $9,099.00
    Chassis
    Front Suspension Independent double wishbone; 5-way preload-adjustable shocks
    Front Travel 6.3 in.
    Front Brake Type Dual hydraulic disc
    Front Tires AT23 x 8-12 Radial
    Rear Suspension Swingarm; 5-way preload-adjustable
    Rear Travel 7.1 in.
    Rear Brake Type Hydraulic Disc
    Rear Tires AT23 x 10-12 Radial
    Frame High-tensile steel
    Dimensions/Capacities
    Dry Weight 516 lbs
    Front Rack Capacity
    Rear Rack Capacity
    Towing Capacity 1102 lbs with optional hitch
    Fuel Capacity 3.8 gal
    Ground Clearance 8.7 in.
    Machine Dimensions (LxWxH) 77.9 x 41.9 x 43.1 in.
    Wheelbase 48.5 in.
    Drive Train
    Drive Train Yamaha On-Command® pushbutton 2WD, 4WD ; Shaft
    Final Drive
    Transmission Yamaha Ultramatic® V-Belt / F,N,R
    Engine
    Engine Type 4-stroke; SOHC, 2 valves
    Displacement 421 cc
    Bore x Stroke 84.5 x 75.0 mm
    Cylinders
    Engine Cooling Liquid-cooled
    Fuel System Mikuni® 33 mm BSR
    Starting System Electric
    Alternator
    General
    Speedometer Digital
    Tachometer
    Odometer Digital
    Lighting Dual 30W Krypton multi-reflector headlights & 21/5W brakelight
    Colors Team Yamaha Blue/White
    Warranty 6 Month (Limited Factory Warranty)

    Current Promotions

    There are currently no promotions available for this product.
